18 PARTS POR MACHIN’P Xo. 119 :i
NO. I’bATK NAM K
37879 — Shiilllc Race 37871 wilti 3781Ì6 and two
3930................................................................
37880 — Shuttle Race 37871 with 37867 aiul two
393i)................................................................
37881 Shuttle Race 37871 wiili 37875 and two
393n, for stitching back strap on
ladies' shoes...................................................
171 e 8857 Shuttle Race Screw...........................................
2102 8858 Tension Disc.......................................................
1560 c 8858 “ Regulatinji Thiiinl) Nut...........................
32572 8858 “ Releasing Di.sc..........................................
37375 8858 “ “ Lever.,....................................................
37387 8858 “ “ “ Connection..........................................
37388 8858 “ “ “ “ Ex­
tension ...........................................................
190 d 8851 Tension Releasing Lever ('onnection Ex­
tension Screw.................................................
7071 8858 Tension Releasing lever Connection E.x-
tension Screw Washer..................................
8285 8858 Tension Releasing Lever Hinge Pin................
24143 8858 “ “ “ Spring..................................................
32574 8858 “ “ Pin...........................................................
1274c 8858 “ Serew Stud................................................
2103 8858 “ Spring........................................................
12149 8858 “ 'I’hread Guard.........................................
37404 Tension complete, Nos. 1274c, 1560c,
2103, 8511, 32572, 32574, 37351 and
two 2102.........................................................
24078 8858 Thread Guard (side of arm).............................
52454 8858 “ Retainer.....................................................
50429c 8858 “ “ Set .Screw...............................................
37389 6112 “ Take-up Crank.........................................
3094 6112 “ “ “ Wedge..................................................
690 e 6112 “ “ “ “ Screw. . . .
37343 6112 “ “ Lever.......................................................
12166 6112 “ “ “ Hinge Pin.............................................
37344 6112 “ “ “ Link......................................................
11204 6112 “ “ “ “ Hinge Pin..
430c 6112 “ “ “ “ “ “ Set
Screw..............................................................
37345 — Thread Take-up Lever complete. Nos.
12166, 37343 and 37344................................
8511 8858 Thread Take-up .Spring...................................
37351 8858 “ “ “ Regulator.............................................
446c 8858 “ “ “ “ Set Screw
19
ACCESSORIES
NO. PLATE NAME
5991; 8851 Machine Bolt with 1524 e , to secure ma­
chine to table..................................................
1524 e 8851 Machine Bolt Nut....................................................
6055 8851 “ “ “ Washer...............................
120342 6120 Oiler (copper-plated) with 120343.......................
120343 6120
“ Spout, 3Pi in. long.......................................
26026 6120 Screw Driver (machine)............................................
26485 6120
“ “ (shuttle tension).............................
8909 6120 Wrench for 1518........................................................
19221 6120 “ “ 1619.................................................
BOBBIN WINDER
NO. PLATE NAME
15072 6114 Bobbin Position Pin...............................................
12168 8854 Bracket...................................................................
692i> 8851 “ Screw.....................................................
12169 8859 Frame......................................................................
12171 ------ PTame complete, Nos. 333 d , 5960, 5961,
5963, 12169 and 15077..................................
32 d 8859 Frame Hinge Screw................................................
5960 8859 P"riction Wheel (leather)......................................
5961 8859 “ “ Washer..................................
333 d 8859 “ “ “ Screw............................
15077 8859 Spindle with 15072....................................................
5963 8859 “ Flange....................................................
12170 8859 Spring.....................................................................
180 f 8859 “ Screw...........................................................
12172 ------ Bobbin Winder complete. Nos. 32 d , 180 f ,
12168, 12170 and 12171................................
BOBBIN WINDER
(Swinging Automatic, Right Hand)
FOR POWER TABLE
NO. PLATE NAME
27552 8854 Base............................................................................
15072 6114 Bobbin Position Pin...............................................
27302 8854 Frame.....................................................................
50356
d 8860 “ Hinge Screw................................................
1620J 8860 “ “ “ Nut.....................................
27303 6114 “ Spring..........................................................
