S I N G E R
Choosing and changing needles
• Raise needle to its highest position.
• Loosen needle clamp screw and remove needle.
• With flat side of needle to the back, insert new needle
up into clamp as far as it will go.
• Tighten needle clamp screw securely.
Changing the needle plate (A), (C)
• Raise needle and presser foot.
• Open slide plate.
•
Lift up needle plate from right corner and slide out
from underfoot.
• To replace needle plate, slide it under pin (1) and push
it firmly to the left.
• Press down until it snaps into place.
Changing screw-on presser feet (H)
• Raise needle and presser foot.
•
Loosen presser foot screw (2) and remove presser foot
with shank (3), guiding it toward you and to the right.
• To replace presser foot with shank, hook shank around
the presser bar and tighten presser foot screw with
the use of a coin.
