iNSTRUCnONb hUK UKDbKINt;
In ordering from this Hat, use CULT the pdrt KINDER In the
FIRST coluim.
The nunber atamped on a Sewing Machine Part la In every caaa
the nunber oT the alngle part only.
Every conblnatlon of parta aent out aa auch baa Ita I'peclflc
nunber, which, althouidi not atanped on the parta, rauat be uaed
when ordering the conblnatlon.
Each number alwaya Indlcatea the SAME PART In vAiatever Hat
It appears, or for whatever machine.
The letters after some of the nunbers Indicate the style of
finish only, as follows:
A-Hardened, Polished, Nickel Plated and Buffed
B-Pollshed, Nickel Plated and Buffed
C-Hardened Only
D-Pollahed Only
E-Soft, Not Polished
F-Hardened and Polished
F.J-Hardened, Polished and Nickel Plated
Q-Brlght Rumbled and Nickel Plated
H-Blued
J-Nlckel Plated Only
K-Hardened and Nickel Plated
L-Brass Plated
M-Oxldlzed
N-Japanned, Dull
P-Japanned, Bright
R-Merllzed
S-Cadralum Plating
T-Copper Plated
T.A-Hardened, Polished, Copper and Nickel Plated and Buffed
T.B-Copper and Nickel Plated and Polished
T.J-Copper and Nickel Plated Only
T.K-Hardened, Copper and Nickel Plated
T.L-Copper and Brass Plated
T.M-Copper Plated and Oxidized
U-Zlnc Plated
V-Sllver Plated
W-Pollshed and Nickel Plated
X-Black Oxide, for Iron and Steel
X.C-Hardened and Black Oxide, for Iron or Steel
Y-Black Nickel Plated Only
Z-Chromlum Plated
Z.A-Hardened,Polished,Nickel Plated,Buffed and Chromium Plated
Z.B-Pollshed, Nickel Plated, Buffed and Chromium Plated
Z.C-Hardened and Chromium Plated
Z.J-Nlckel and Chromium Plated
These letters MUST BE USED when, they appear In the list; and
AFTOl the number as In the list.
In this series;
1 to 1500 , 50001 tr 51500 and 140001 to 143000
are Screw Numbers
1501 to 1800 and 51501 to 51800 are Nut Numbers
1001 to 3000 and 51801 to 53000 are Roller Numbers
3001 to 50000 and 53001 to 140000 and 143001 to
190000 are Sewing Machine Parts, 190001 and upward
are numbers of Electrical Parta.
The figures In the second column refer only to the plates.
Illustrating the parts, and are NOT TO BE USED In ordering.
Parts marked with an asterisk (•) are furnished only vdien
repairs are made at factory.
When ordering parta which differ as to Gauge (the distance
between seams) the Gauge, as well as the Number must be given on
order.
LIST OF PARTS COMPLETE
FOR
A\ACI-IINE No. 147-104
For Seat Seaming Light and Medium Trousers. Two needles,
two loopers. Needles set tandem 3/16 inch apart. Ball beating.
Needle bar stroke I 7/32 inches. The loopers are arranged so
that they may be thrown out of position for convenience in thread-
■^ing. An improved oiling system automatically oils all of ^he princi­
pal bearings of the machine. Speed 4000 R. P. M.
No .
•131446
Plate
Arm
Name
, upper and lower (solid) with
15404, 68483, two 15405 and
131022...........................................................
448J,
four
68428 20524 Arm Bottom Cover................................................
68424 20524 " ’’ Qasket (cork)........................
1057C 20530 " " Screw.....................................
SOiiOBR 20530 Hole Plug Screw, for access to
Connecting Rod (upper bearing).
Crank
134017 20530 Arm Hole Plug Screw Washer...............................
68350 20530 Oil Cup, for oiling Arm Rock
Front Bearing.................................................
Shaft
