The Lincoln Electric Company
Qeveland, Ohio 44117
Sec. J7.3
Page 107-0
50 AND 60 # WIRE REEL SUPPORT
/
\
Parts List P-107-0
ITEM
PART NAME AND DESCRIPTION
NO.
REQ’D.
Wire Reel Support Assembly, includes;
1
1
W i re Ree1
1
3
Reel Support
1
10
Reel Mounting Shaft Assembly 1
'-107-F
Optional Wire Reel Cover Parts Kit, includes;
1
2
\iire Reel Housing
1
if
Flatwasher
6
5
Lockwasher
3
6
Hex Nut
3
7
Hex Head Screw
3
8
Insulating Washer
12
9
Insulating Tube
1
13
Insulatina Tube
2
Optional Door Parts Kit, includes;
(Wire Reel Cover Must Be Installed.)
1
Door and Hinge Welded Assembly
1
Catch
1
Sems Screw (Catch Mounting)
2
Sealing Panel
1
January 1973
■23-
