CONTENTS OF HARDWARE PACK

Parts Bag contents shown full size

(2) Sheet

Metal

Screws

#10-16 X

1/2

(1) Large Flat Washer

{1 ) Locknut 3/8-24

(1 ) Shoulder Bolt 5/16-18

(1 ) Hex Bolt 1 /2-13 x 1

(

1

) Lock Washer 1/2

{1 ) Washer 17/32 x 1 -3/16x12 Gauge

(

2

) Hex Bolts 1/4-20x3/4

{

2

} Hex Nuts 1/4-20

^

(

2

) Lock Washers 1/4

(2) Washers 9/32 x 5/8 x 16 Gauge

Parts packed separately in carton

Steering

Wheel

Battery

n

----------------------

—

1 *

■

Steering

Boot

« ^

r *

i

*

i

*

1

*

. 1

Owner's Manual

Parts Bag
