SPECIFICATION CHART
Model No. 919.154020 919.154320 919.154120 919.154420
Horsepower 2 2 2 2
Displacement CFM 10.0 10.0 10.0 10.0
Bore 2%" 23/8" 23/s" 23/8"
Stroke 1.13" 1.13" 113" 1.13"
Voltage-Single Phase 120 120 120 120
Minimum Branch Circuit Requirement *15 amps *15 amps *15 amps *15 amps
'Fuse Type “Fusetron” “Fusetron” “Fusetron” “Fusetron”
**Type T **Type T **Type T **Type T
Air Tank Capacity 12 gal. 20 gal. 12 gal. ASME 20 gal. ASME
Approximate Cut-in Pressure 80 80 80 80
Approximate Cut-out Pressure 100 100 100 100
SCFM @ 40 psig 7.0 7.0 7.0 7.0
SCFM @ 90 psig 5.6 5.6 5.6 5.6
CAUTION
These compressors can be operated on a 15 amp circuit if:
1. Voltage supply to circuit is normal.
2. Circuit is not used to supply any other electrical needs (lights, appliances, etc.)
3. Extension cords comply with specifications in owners manual.
4. Circuit is equipped with 15 amp circuit breaker or 15 amp Fusetron Type “T” time delay fuse.
If any of the above conditions cannot be met, or if operation of the compressor repeatedly causes
interruption of the power it may be necessary to operate it from a 20 amp circuit. It is not necessary to
change the cord set.
* A circuit breaker is preferred. Use only a fuse or circuit breaker that is the same rating as the branch circuit the air
compressor is operated on. If the air compressor is connected to a circuit protected by fuses, use dual element time
delay fuses (Buss Fuestron Type “T” only).
GLOSSARY
CFM: Cubic feet per minute.
SCFM: Standard cubic feet per minute; a unit of meas­
ure of air delivery.
PSIG: Pounds per square inch gauge; a unit of meas­
ure of pressure.
ASME: American Society of Mechanical Engineers;
made, tested, inspected and registered to meet the
standards of the ASME.
U.L. LISTED: Samples of compressor outfits, taken
from production, were submitted to U.L. and found to
comply with their requirements for design and
performance.
ACCESSORIES FOR USE WITH SEARS AIR COMPRESSORS
The following accessories are available through the current general sales catalog or at full-line Sears stores.
Cut-In Pressure: While the motor is off, air tank pres­
sure drops as you continue to use your accessory.
When the tank pressure drops to a certain low level the
motor will re-start automatically. The low pressure at
which the motor automatically re-starts is called “cut-in
pressure”.
Cut-Out Pressures: When you turn on your air com­
pressor and it begins to run, air pressure in the air tank
begins to build. It builds to a certain high pressure
before the motor automatically shuts off - protecting
your air tank from pressure higher than its capacity.
The high pressure at which the motor shuts off is called
“cut-out pressure”.
• SPRAY GUNS
>
BLOW GUNS
• AIR CAULKING GUNS
■ AIR POWERED WASHER GUNS
>
SANDBLASTERS
■AIR BRUSHES
>
AIR LINE FILTERS
•TIRE AIR CHUCKS
• PAINT TANKS
• AIR TANKS
• INFLATER KITS
• QUICK CONNECTOR SETS
(various sizes)
• VISCOSIMETER
• AIR PRESSURE REGULATORS
• OIL FOG LUBRICATORS
■ AIR TOOLS;
Sanders
Drills
Impact wrenches
Hammers
■AIR HOSE:
VY, Vie" or %" I.D.
in various lengths
