Sears 390.2508 - Manual (Page 12)

REPAIR PARTS
To Order Parts, Call
Sears Product Service,
1-800-366-7278
18 I
r
16
15^
1
14
Model 390.2508
Key
No. Part Number
Qty.
Used Description
1# J218-953C 1 Motor - 115/230V
2 17351-0009 1 Water Siinger
3* N203-12P 1 Seal Piate Assembly
4 J3-2 1 Seai Piate Insert
5 U9-390 1 0-Ring
6 U109-6A 1 Shaft Seai
7 J105-40PF 1 impeiler
8 C35-41 1 Rubber Pad
9 N1-28P 1 Diffuser
10 U30-738SS 2 Capscrew #10-16 Hex Head
11" N176-35PE 1 Pump Body Assembiy
12 N76-35PE 1 Pump Body
12A U9-226 1 0-Ring
12B N166-5P 1 Check Vaive
13t - 1 Pipe Plug l/S" NPT
14 U111-212T 2 90° Hose Barb
15 U37-669P 1 Switch Tube
16 J20-18 1 Gasket
17 N76-29P 1 Pump Body Jet insert
18 U30-742SS 4 Capscrew #10-16
19 N34P-19 1 Nozzle #45
20 N32P-66 1 Venturi
21 U9-201 1 0-Ring
22 J104-9F 1 Base Assembiy Painted
23t - 4 Lock Washer 3/8"
24t - 4 Nut 3/8“-16
25 C35-5 1 Rubber Pad
26 2781 1 Pressure switch
27t - 1 Locknut 1/2"
28 L43-5C 1 Connector 1/2"
# For repair or service to motors, aiways give the motor modei number and any other data found on the motor modei piate.
’ Inciudes Key Nos. 4 and 5.
** inciudes Key Nos, 12,12A, 12B, and 16 through 21,
t Standard hardware item, may be purchased locaiiy.
