CONTENTS OF HARDWARE PACK

Parts Bag contents shown full size

(1) Washer 17/32 x 1-3/16 x 12 Gauge

(3) Retainer Springs

Double Loop

(4) Retainer Springs

Single Loop

(2) Hex Bolts 1/4-20 x 3/4

(2) Hex Nuts 1/4-20

(2) Washers 9/32 x5/8x 16 Ga.

(2) Lock Washers 1/4

(2) Wing Nuts 1/4-20

Parts packed separately in carton

Seat

Battery acid

.Ji ' a.

steering Wheel

Battery

Parts Bag

Owner's Manual

Parts bag contents not shown full size

(2) Gauge Wheels

(2) Shoulder Bolts

(2) Washers Lock Nuts

3/8

7/8

14 Gauge

(2) Front Link Assemblies

(2) Battery Carriage Bolts 1/4-20 x 7-1/2

"T3----- cr

Terminal Guard

Steering Wheel Insert

(2) Keys

15° Slope Sheet

Battery Caps

and Instructions
