Page 103

Cavity
Maxi Fuse
Mini Fuse
Description
F19
7.5 Amp Brown
Air Conditioning
F20
30 Amp Green
Rear Defroster
F21
5 Amp Tan
Key Unlock
F22
10 Amp Red
Primary ECM Loads
F23
20 Amp Yellow
BSM System
F24
5 Amp Tan
BSM System, Positive Key and
Steering Angle Sensor
F30
15 Amp Blue
Fog Lamp
F81
40 Amp Orange
Trailer Hitch Module And Plug
F82
20 Amp Yellow
Available
F83
20 Amp Yellow
Fuel Pump
F84
15 Amp Blue
AT Module
F85
15 Amp Blue
Rear Power Outlet 12V
F86
15 Amp Blue
IP Power Outlet 12V
F87
5 Amp Tan
IBS
F88
7.5 Amp Brown
External Mirror Defrost
Interior Fuses
The interior fuse panel is part of the Body Control Module (BCM) and is located on the
driver's side under the instrument panel.
Cavity
Mini Fuse
Description
F53
5 Amp Beige
KL 30 (+30) - IPC
F38
20 Amp Yellow
Central Doors Locking
F36
10 Amp Red
KL 30 (+30) - TPMS,
EOBD, HVAC, Radio
F43
15 Amp Blue
Bi-Directional Washer
Pump
F48
20 Amp Yellow
Passenger Power Windows
F50
7.5 Amp Brown
KL 15 (+15) - Air-Bag
F51
7.5 Amp Brown
KL 15 (+15) - External Mir-
ror Adjustment Command,
HVAC, RVC, HWB Coils
F37
5 Amp Beige
KL 15 (+15) - Brake Pedal
Switch (N.O.), IPC, Brake
Pedal Switch (N.C.)
F49
5 Amp Beige
KL 15 (+15) - PAM, CSS
Lighting, ECM Backlight-
ing, TTM
F31
5 Amp Beige
KL 15a (INT A) - HWB, MCO
F47
20 Amp Yellow
Driver Power Windows
