FUSES
WARNING!
• When replacing a blown fuse, always use an appropriate replacement fuse with
the same amp rating as the original fuse. Never replace a fuse with another
fuse of higher amp rating. Never replace a blown fuse with metal wires or any
other material. Failure to use proper fuses may result in serious personal injury,
fire and/or property damage.
• Before replacing a fuse, make sure that the ignition is off and that all the other
services are switched off and/or disengaged.
• If the replaced fuse blows again, contact an authorized dealer.
• If a general protection fuse for safety systems (air bag system, braking system),
power unit systems (engine system, gearbox system) or steering system blows,
contact an authorized dealer.
Underhood Fuses
The Front Distribution Unit is located on the right side of the engine compartment,
next to the battery. To access the fuses, remove fasteners and remove the cover.
The ID number of the electrical component corresponding to each fuse can be found
on the back of the cover.
Cavity Maxi Fuse Mini Fuse Description
F01 60 Amp Blue Body Controller
F02 40 Amp Orange
Front Heated Seats, Second 12
Volt IP Outlet
F02 60 Amp Blue
Rear Power Window Including
Front Heated Seats, Second 12
Volt IP Outlet
F03 20 Amp Yellow Ignition Switch
F04 40 Amp Orange BSM System Module
F05 50 Amp Red Available
F06 20 Amp Yellow Radiator Fan - Low Speed
F07 50 Amp Red Radiator Fan - High Speed
F08 40 Amp Orange Blower Motor
F09 10 Amp Red Available
F10 15 Amp Blue Horn
F11 10 Amp Red Secondary Loads ECM
F14 15 Amp Blue High Beam
F15 15 Amp Blue Available
F16 5 Amp Tan ECM and Transmission Shifter
F17 25 Amp Clear ECM Power Loads
F18 5 Amp Tan ECM Load, Main Relay
M A I N T A I N I N G Y O U R V E H I C L E
