Air Seat Adjustment
The seat is equipped with a mechanical spring system and hydraulic shock absorber
to ensure maximum comfort and safety. The system of springs also effectively
absorbs impact from uneven road surfaces.
• Use the weight adjustment knob to set
the required setting based on body
weight, with settings between 88 lbs
(40 kg) and 286 lbs (130 kg).
Swivel Seat Adjustment
The swivel seat lever is located at the lower front inboard side of the seat.
• The seat may be turned 180° toward
the seat on the opposite side and ap-
proximately 35° toward the door.
• The seat may be locked in the driving
position or at the 180° position.
• To swivel the seat, pull the swivel seat
lever outward, turn the seat to the
desired position and release the lever.
• The swivel seat must be in the forward,
locked position to allow the vehicle
to shift out of park, or move forward/
reverse.
Weight Adjustment Knob
Swivel Seat Lever
