1. Introduction
The GM100 is a microprocessor-based controller for industrial engines. It is
based on the Controls, Inc. 1100-000 series controller platform.
•
The product is housed in an 14”W x 10”H x 10”D
metal enclosure.
•
The controller is designed to accept generic wiring
harnesses using circuit board mounted Molex
connectors.
•
Color-coded engine and AC wiring harnesses are
available from Controls, Inc. for simple installations.
•
The backlit digital display is 1”H x 4”W with two rows
of 16 characters. Character height is approximately
½”. Operating temperature is –20C to +70C.
Extreme temperature ranges available.
•
Operating voltage is 12 or 24 VDC.
•
AC Voltages can range from single or three phase
systems up to 600 VAC. Controller automatically
senses.
•
Current transformers can be used up to 2000:5
amps.
•
Engine pre alarm and alarm parameters are
monitored with corresponding amber or red LED
illuminations above the digital display.
•
Optional Remote Annunciation or Remote Relay
modules available for expansion.
PART NUMBER BREAKDOWN
GM100 14 252 K
Model
Enclosure
14X10X10
CT Size (250:5)
And Qty (2)
“Kit” Includes
Harness
Press / Temp Senders
(2) Diodes, Fuse
