Winco 2-Wire Conversion Instructions ULPSS8B2W/E - Manual (Page 2)

4. Remove the battery negative (-)
cable if the battery is installed.
5. Unplug the wiring harness “D”.
6. Remove the two bolts “B” and remove
the circuit breaker cover panel.
7. Remove the 6 torx screws “G” from the
tower assembly.
8. Push the plastic grommet “H” into the
box to ease in pulling the wiring harness
through the hole.
9. Remove the 4-wire controller by pulling
it forward while guiding the wiring harness
through the hole “H”.
10. Remove the plastic grommet and put
it aside to re-install later.
11. Install 2-wire controller “F” by guiding
