Winco 4-Wheel Dolly Kit Assembly Instructions for 12kW Gen-Sets - Manual (Page 2)

2 12048-00 16199-011I
Open hardware bag and separate components.
FASTENERS & MISC. COMPONENTS
(not shown in actual size)
•
STEP 1
9
11 12
13
21
14
15
16 17
19
18
20
HARDWARE & FASTENER LIST
REF # PART # DESCRIPTION QTY
9 56842-005 1/4” X 2“ Carriage Bolt 2
10 56842-004 1/4” X 1 3/4 “ Carriage Bolt 4
11 479-000 1/4“ Split Lock Washer 6
12 47517-000 1/4” Nylock Nut 6
13 1178-000 Flat Washer 8
14 64327-000 Hub Cap 4
15 96286-006 Nylon Flat Washer 2
16 64688-007 Spacer 4
17 93402-002 Hole Plug 2
18 465-000 5/16” X 7/8” Bolt 8
19 458-000 5/16” Nylock Nut 8
20 480-000 5/16” Split Lock Washer 8
21 62912-000 Foam Strip 1
22 526-000 Flat Washer 8
10
22
