3 3030-00 699-025I
Remove the generator from the pallet and block generator up 8 to 0 inches to
gain access to the botton of the cradle assembly. A lifting jack or hoist may also
be used if available.
•
STEP 2
STEP 3
Bolt shock mounts (ref. 9) to the bottom of the foot bracket (ref. 3) using hardware
(ref. 4 & 2). Place foot bracket (ref. 3) into the front cross channel of the cradle
and bolt on with hardware (ref. 8, 9, 20).
•
