Winco WC10000VE/E Dolly Kit Assembly Instructions - Manual (Page 2)

2 3030-00 699-025I
Open hardware bag and account for all fasteners and components.
FASTENERS & MISC. COMPONENTS
(not shown in actual size)
•
FASTENER & COMPONENT LIST
REF #
PART # DESCRIPTION QTY
7 9245-000 5/6” X 5” Bolt 4
8 64688-006 Spacer 2
9 209-000 Shock Mount 2
0 64327-000 Hub Cap 2
93402-002 Hole Plug 2
2 56842-005 /4” X 2” Carriage Bolt 2
3 4757-000 /4” Nylock Hex Nut 2
4 466-000 /4” X 3/4” Bolt 2
5 6292-000 Foam Strip
6 78-000 Flat Washer 2
7 96286-006 Nylon Flat Washer 2
8 9672-0 5/6” X 4” Bolt 2
9 6249-000 5/6” Flange Lock Hex Nut 6
20 526-000 Flat Washer 6
2 6248-000 /4” Flange Lock Hex Nut 2
22 6343-000 Axle End Protector 2
23 5775-09 Axle Bracket 2
STEP 1
7 8
9
10
11
12
13
14
16
17 18
19 20
21
22
15
