2 2038-02 699-020I
Open hardware bag and account for all fasteners and components.
FASTENERS & MISC. COMPONENTS
(not shown in actual size)
•
20
13
14
18
17
19
15
16
9
8
10
11
FASTENER & COMPONENT LIST
REF #
PART # DESCRIPTION QTY
8 56842-005 /4” X 2“ Carriage Bolt 2
9 4757-000 Nylock Hex Nut 6
0 6248-000 /4“ Flange Nut 2
479-000 /4“ Split Lock Washer 2
2 56842-004 /4” X 3/4 “ Carriage Bolt 4
3 6249-000 5/6” Flange Nut 6
4 466-000 /4” X 3/4” Bolt 2
5 64688-007 Spacer 2
6 78-000 Flat Washer 4
7 64327-000 Hub Cap 2
8 209-000 Shock Mount 2
9 96286-006 Nylon Flat Washer 2
20 6292-000 Foam Strip
2 9672-0 5/6” X 4” Bolt 6
22 526-000 Flat Washer 6
23 93402-002 Hole Plug 2
STEP 1
21
22
23
12
