ORDER CODE
T510 - AB - CD - EF - GH ( without day-night mode )
T560 - AB - CD - EF - GH ( with day-night mode )
A Output no. 1 ( controlled device ) Type
0 Not installed
5 "SSR" with 3-32 Vdc input Pulsed 0/5 Vdc
6 0 to 10 Vdc actuator, voltage relay or "SCR" * 0 to 10 Vdc
7 0 to 10 Vdc high cooling signal for Vdc relay Higher signal
B Output no. 2 ( controlled device ) Type
0 Not installed
1 Relay, thermal relay, two position motor Isolated Triac
2 Normally open thermal valve Isolated Triac
3 Normally close thermal valve Isolated Triac
4 "SSR" with 24 Vac input Isolated Triac
5 "SSR" with 3-32 Vdc input Pulsed 0/5 Vdc
C Output no. 1 and 2 control mode
1 Heating, reverse acting, ( RA ) ∗ Standard
2 Cooling, direct acting, ( DA )
3 Heating, RA ( no. 1 ) and cooling, DA ( no. 2 )
4 Cooling, DA ( no. 1 ) and heating, RA ( no. 2 )
D Main control sensor location
1 Room, inside thermostat, or ( duct return air**) ∗ Standard
2 Duct supply air **
** Order with S60 or S70 sensor
E Setpoint adjustment
1 User adjustable ∗ Standard
2 Blind cover
F Scale
1 10 °C to 32 °C ∗ Standard
2 50 °F to 90 °F
3 -18 °C to 82 °C ∆
4 0 °F to 180 °F ∆
G Output no. 3
1 Normally cooling, ( DA ) ∗ Standard
2 Normally heating, ( RA )
H Maximum running time of tri-state floating actuator
1 1 minute
2 2 minutes
... etc.
9 9 minutes
Order Example: T560 - 75 - 41 - 12 - 12
One higher signal cooling output and one "SSR" 3-32 volts heating output.
Main sensor located inside the room. Setpoint adjustable by user.
Scale 50
°F to 90 °F. The output no. 3 is a damper with
a travel time of 2 minutes used in cooling mode.
∆ Note: These models have a vertical cover.
Note: remote sensor separately
WIRING
NOTE: TERMINALS 5, 6, 8, 9 AND 10 CAN BE WIRED TOGETHER
BETWEEN EACH THERMOSTAT IF POLARITY IS RESPECTED
Power supply 24 Vac -15% +10%
50/60 HZ 2 VA
COMMON
24 VAC
24VAC
5
6
POWER SUPPLY 24 Vac.
IMPORTANT: IF USING A COMMON TRANSFORMER
RESPECT POLARITY (COMMON AND 24 VAC)
BETWEEN EACH THERMOSTAT
Day night mode T560 only
CLOSE =
NIGHT
SET BACK
COMMON
INPUT
DAY / NIGHT 6
8
DAY NIGHT MODE
1 CONTACT USED FOR ALL
THERMOSTAT USING THE
SAME TRANSFORMER
Output #2 code A= 1, 2, 3 & 4 Triacs
RELAY OR THERMAL
VALVE 24 VAC
CONTACT
OUTPUT 3
4
OUTPUT #2 USING RELAY WITH ISOLATED TRANSFORMER
R
24VAC
Output #2 code A= 1, 2, 3 & 4 Triacs
RELAY OR
24 VAC
THERMAL VALVE
CONTACT
OUTPUT
COMMON
24 VAC
24VAC
5
6
OUTPUT #2 USING SAME TRANSFORMER TO OUTPUT
3
4
Output #1 code A= 5 Pulsed 0/5 Vdc
Output #2 code B= 5 Pulsed 0/5 Vdc
SOLID STATE
RELAY
3-32 VDC
TRIGGER
LOAD
COMMON
0/5 V
6
OUTPUT #1 AND/OR #2 USING PULSED 0/5 Vdc
AND / OR
4 10
USE TERMINALS 6 & 10 FOR OUTPUT #1
USE TERMINALS 4 & 6 FOR OUTPUT #2
Output #1 code A=6 & 7Analog 0 to 10 Vdc
0 TO 10 VDC
COMMON
0 TO 10 Vdc
6
10
OUTPUT #1 USING 0 TO 10 Vdc
ELECTRONIC ACTUATOR, SCR,
OR VOLTAGE RELAY
Output #3 Tri-State Floating
OPEN
CLOSE
24 Vac
DAMPER
ACTUATOR
OUTPUT #3
1
2
OUTPUT #3 TRI STATE FLOATING
COMMON
24 VAC 5
6
TRI STATE IF OPERATION OF THE ACTUATOR IS
REVERSED, FLIP REVERSING SWICH ON
ACTUATOR OR REVERSE WIRES #1 & #2
Remote main temperature control sensor
Room or return control code D= 1,
Supply control code D=2
EXTERNAL
SENSOR
NOTE: REMOVE
INTERNAL J4 JUMPER
7
REMOTE MAIN CONTROL SENSOR
COMMON 6
VICONICS
DUCT S60 OR S70
ROOM S80 IMMERSION S90
Power limit input
Analog 0 to 10 Vdc
LIMIT INPUT
0 TO 10 Vdc
COMMON
0 TO 10 Vdc
6
9
POWER LIMIT INPUT USING 0 TO 10 Vdc
ENERGY
SYSTEM
MANAGEMENT
