ORDER CODE
T100 - AB - CD - EF ( without day-night mode )
T150 - AB - CD - EF ( with day-night mode )
A Output no. 1 ( controlled device ) Type
1 Relay, thermal relay, two position motor Isolated Triac
2 Normally open thermal valve Isolated Triac
3 Normally close thermal valve Isolated Triac
4 "SSR" with 24 Vac input Isolated Triac
5 "SSR" with 3-32 Vdc input Pulsed 0/5 Vdc
6 0 to 10 Vdc actuator, voltage relay or "SCR" 0 to 10 Vdc
B Output no. 2
0 Non available
C Output control mode
1 Heating, reverse acting, ( RA ) ∗ Standard
2 Cooling, direct acting, ( DA )
D Main control sensor location
1 Room, inside thermostat, or ( duct return air**) ∗ Standard
2 Duct supply air**
** Order with: S60 or S70 sensor
E Setpoint adjustment
1 User adjustable ∗ Standard
2 Blind cover
F Scale
1 10 °C to 32 °C ∗ Standard
2 50 °F to 90 °F
3 -18 °C to 82 °C ∆
4 0 °F to 180 °F ∆
Example: T150 - 50 - 31 - 12
One "SSR" 3-32 Volts heating output
and one normally close thermal valve cooling output.
Main sensor located inside the room
Adjustable setpoint. Scale 50
°F to 90 °F.
∆ Note: These models have a vertical cover.
Note: Order remote sensors separately
WIRING
NOTE: WITH THE PROPER CODES, TERMINALS 5, 6 AND 8 CAN BE
WIRED TOGETHER BETWEEN EACH THERMOSTAT IF POLARITY IS RESPECTED
Power supply 24 Vac -15% +10%
50/60 HZ 2 VA
COMMON
24 VAC
24VAC
5
6
POWER SUPPLY 24 Vac.
IMPORTANT: IF USING A COMMON TRANSFORMER
RESPECT POLARITY (COMMON AND 24 VAC)
BETWEEN EACH THERMOSTAT
Day night mode T150 only
CLOSE =
NIGHT
SET BACK
COMMON
INPUT
DAY / NIGHT 6
8
DAY NIGHT MODE
1 CONTACT USED FOR ALL
THERMOSTAT USING THE
SAME TRANSFORMER
Output #1 code A= 1, 2, 3 & 4 Triacs
RELAY OR THERMAL
VALVE 24 VAC
CONTACT
OUTPUT 3
4
OUTPUT #1 USING RELAY WITH ISOLATED TRANSFORMER
R
24VAC
Output #1 code A= 1, 2, 3 & 4 Triacs
RELAY OR
24 VAC
THERMAL VALVE
CONTACT
OUTPUT
COMMON
24 VAC
24VAC
5
6
OUTPUT #1 USING SAME TRANSFORMER TO OUTPUT
3
4
Output #1 code A= 5 Pulsed 0/5 Vdc
SOLID STATE
RELAY
3-32 VDC
TRIGGER
LOAD
COMMON
0/5 V
6
4
OUTPUT #1 USING PULSED 0/5 Vdc
Output #1 code A= 6 Analog 0 to 10 Vdc
COMMON
0 TO 10 Vdc
6
OUTPUT #1 USING 0 TO 10 Vdc
ELECTRONIC ACTUATOR, SCR,
OR VOLTAGE RELAY
4
Remote main temperature control sensor
Room or return control code D= 1,
Supply control code D=2
EXTERNAL
SENSOR
NOTE: REMOVE
INTERNAL J4 JUMPER
7
REMOTE MAIN CONTROL SENSOR
COMMON 6
VICONICS
DUCT S60 OR S70
ROOM S80 IMMERSION S90
