4
Room Temperature Control With:
0 to 10 Vdc SCR Power Controller
Dip switch position S1 S2
Heating application 0 1
Supply Temperature Control With:
Remote Sensor & 4-32 Vdc SSR’s
Dip switch position S1 S2
Heating application 1 0 The output is rated at 20 mA max at 8 Vdc.
Supply Temperature Control With:
Remote sensor & 0 to 10 Vdc SCR Power Controller
Dip switch position S1 S2
Heating application 1 0
Viconics Electronics Inc. 9245, Langelier Blvd, St-Leonard, Quebec, Canada H1P 3K9 www.viconics.com
[email protected]
028-0071 LIT-C1025-E03
Supply air
temperature
sensor
Common
24 Vac
0 to 10 Vdc
Remote Sensor
Vdc Pulsed
4-32 Vdc SSR's
3
4
5
7
+
-
Vdc
pulsed
6
Common
24 Vac
0 to 10 Vdc
Remote Sensor
Vdc Pulsed
SCR power controller
0 to 10
Vdc
3
4
6
5
7
Supply air
temperature
sensor
Common
24 Vac
0 to 10 Vdc
Remote Sensor
Vdc Pulsed
SCR power controller
0 to 10
Vdc
3
4
6
5
7
Modulating Electric Duct Heater
0 to 10 Vdc SCR Power Controller
5 0
7 0
6 0
9 0 8 0
F
Modulating Electric Duct Heater
0 to 10 Vdc SCR Power Controller
5 0
7 0
6 0
9 0 8 0
F
Modulating Electric Duct Heater
c/w 4-32 Vdc Triggered SSR
+
-
50
70
60
90 80
F
