The zone controller shall have a binary input that can be configured as follows:
BI1 Binary input no.1 configuration
Default: None
(None): No function will be associated with the input. Point
can still be monitored through the wireless network.
(Motion NO): Used in Occupied Mode only to toggle from the
Occupied set points to the Stand-By set points when no
motion is detected for 60 minutes at the zone.
As soon as motion is detected at the zone, the Occupied set
points resumes.
Contact opened = No motion detected.
Contact closed = Motion detected
(Motion NC): Used in Occupied Mode only to toggle from the
Occupied set points to the Stand-By set points when no
motion is detected for 60 minutes at the zone.
As soon as motion is detected at the zone, the Occupied set
points resumes.
Contact opened = Motion detected.
Contact closed = No motion detected
The zone controller shall be capable of receiving the outdoor air temperature signal from the RTU
controller to lockout (if necessary) the zone’s analog reheat and/or the zone’s perimeter heating.
The zone controller shall have configurable temporary or permanent local override set points.
When the “temporary set points” mode is enabled, once the temporary occupancy timer expires,
the set points will revert back to their default values.
The zone controller shall have adjustable maximum heating and minimum cooling set points to
prevent locking conditions at the Rooftop Unit controller by having set points that are not
reachable.
