Use and operation
Notes on operation
Gas
Correction factor cold cathode
Correction factor Pirani
Air / N
2
-
1.00
CO
2
0.74
0.89
H
2
2.39
0.58
He
5.93
1.02
Ne
3.50
-
Ar
0.80
1.59
Kr
0.60
-
Xe
0.41
-
The vacuum gauge head MPT 100 / MPT 200 consists of two components: one cold cathode sensor and
one Pirani sensor. The pressure measurement is dependent on the gas type. The vacuum gauge head
is factory-set for operation with air / N
2
.
Use the following correction factors when working with other gases in the pressure range below 0.1
mbar:
Connecting and starting operation
Vacuum connection:
➨
Remove the protective cover and keep.
➨
Connect the vacuum gauge head via small flange to the vacuum application.
☞
The vacuum gauge head may be mounted in any orientation, though an orienta-
tion in which condensate cannot get into the measuring chamber is to be pre-
ferred.
☞
Avoid contamination (oil/oil mist) of the measurement chamber when generating the vacuum with an
oil-filled vacuum pump.
☞
Do not mount the vacuum gauge head directly at the oil-sealed pump. Use only vacuum lines with a
sufficient diameter.
☞
Inside a vacuum system the vacuum might not be uniform (e.g., in case of evaporation). Therefore
choose carefully the position where to connect the vacuum gauge head.
☞
Condensate and deposits in the measuring chamber falsify the measurement result.
☞
Soiling and damage affect the function of the vacuum gauge head.
☞
If residues occur or when working with aggressive or condensable substances, install a gas washing
bottle in front of the vacuum gauge head MPT 100 / MPT 200.
Electrical connection / VACUU•BUS
Voltage supply and readout of the vacuum gauge head via VACUU•BUS line by the vacuum gauge
DCP 3000. Maximum cable length inside buildings: 30m. Extension cable VACUU•BUS 2m: order-no.
612552.
NOTICE
