Type MPT 200
Measuring principle
combined vacuum gauge head comprising two
components: thermal conductivity according to Pi-
rani and cold cathode tube; dependent on gas type
Measuring range (absolute)
1*10 3 mbar - 5*10 -9 mbar
(7.5*10 2 Torr - 3.7*10 -9 Torr)
Repeatability
(in percent of displayed value)
1*10 1 mbar - 1*10 -2 mbar:
(7.5*10 0 Torr - 7.5*10 -3 Torr):
1*10 -2 mbar - 1*10 -8 mbar:
(7.5*10 -3 Torr - 7.5*10 -9 Torr):
±2%
±7%
Measurement uncertainty
(in percent of displayed value
at constant temperature)
1*10 3 mbar - 1*10 2 mbar:
(7.5*10 2 Torr - 7.5*10 1 Torr):
1*10 2 mbar - 1*10 1 mbar:
(7.5*10 1 Torr - 7.5*10 0 Torr):
1*10 1 mbar - 2*10 -3 mbar:
(7.5*10 0 Torr - 1.5*10 -3 Torr):
2*10 -3 mbar - 1*10 -8 mbar:
(1.5*10 -3 Torr - 7.5*10 -9 Torr):
±50%
±30%
±10%
±25%
Maximum permissible pressure
at vacuum gauge head (absolute)
1.5 bar (1125 Torr)
Measuring cycle 10 ms
Maximum permissible temperature of gaseous
media at measurement connection
continuous operation: 60°C,
for short periods (less than 5 minutes) up to 80°C
Maximum permissible temperature during
bake-out
max. 180°C
(without electronics and magnetic unit)
Ambient temperature range (operation) +5°C to +60°C
Ambient temperature range (storage) -40°C to +65°C
Permissible relative atmospheric moisture
during operation (no condensation)
30% to 85%
Maximum permissible installation altitude above
mean sea level
2000 m
Range of supply voltage
(via VACUU•BUS cable)
24 VDC
Max. power consumption (supply) 3 W
Degree of protection according to IEC 529 IP 54
Weight 555 g
Dimensions L x W x H 138 mm x 66 mm x 53 mm
Vacuum connection small flange KF DN 25
Cable length approx. 2.0 m
