Professional Surround Sound Tuning Kit Crestron
Transfer the MultEQ ® XT Filters
Transfer the correction filters you have calculated by clicking the Transfer to
Crestron button. This process temporarily stores the filters so you can listen to them
before deciding to permanently save them. Previously saved filters will not be erased
until you click the Save Permanently to Crestron button.
The Transfer to Crestron process may take several minutes. The download status
bar will indicate the progress of the transfer.
NOTE: If the MultEQ ® Pro application is turned off before the transfer is
completed, the MultEQ ® XT filters will be erased. The application will show a
warning window asking you to confirm whether you wish to quit without saving.
NOTE: If the USB cable is disconnected between the processor and the PC during
this process or before the process is complete, all measurements will be lost. If this
happens, you must close the application, reopen it and start from the beginning of the
application.
MultEQ ® Pro On/Off Demo
After the results are transferred, the Audyssey Demonstration buttons for MultEQ On
and Off will become unlocked and usable. You can use these buttons to demo
MultEQ
® XT filters before deciding to save them permanently.
Insert program material into your source component. Play a track from the disc. Use
the MultEQ On and Off buttons to demo the MultEQ
® XT filters.
NOTE: If the customer is present during the On/Off demo, have them sit or stand
within the room area you measured earlier. If they are not positioned inside this area,
it is less likely they will hear the full effect of the MultEQ
® XT filters.
ONLY
Dynamic EQ & Dynamic Volume On/Off Demos
When MultEQ is On, the Dynamic EQ On and Off buttons and the Dynamic Volume
On and Off buttons will become unlocked and usable.
At lower playback volumes, human hearing sensitivity in the bass and treble ranges
is diminished. Dynamic EQ compensates for this by boosting the bass and treble
ranges during periods of low playback volume.
The Dynamic Volume presets can be auditioned as well. The Mode dropdown allows
for selection between the Day, Evening and Midnight presets. (Refer to “Audyssey
Settings” on page 17.)
Change the MultEQ ® XT Filters
There are two options for changing the MultEQ ® XT filters:
1. Add more measurement positions or redo your measurements. Click the
back arrow until you get back to the “Measurement” screen (refer to
“Measurement” which starts on page 8).
2. Calculate the MultEQ ® XT filters with a different target curve. Click the
back arrow to go back to the “Target Sound Options” screen (refer to
“Target Sound Options” which starts on page 12).
14 • Professional Surround Sound Tuning Kit Operations Guide – DOC. 6565C
