Touchstone 80004 Sideline Fireplace User Manual
Page 4
3
INSTALLATION
1. Using the Philips Screw Driver "+" to take off the two screws in the front two sides (Figure A), then
have two people to take off the Glass Panel (Figure B)
2. Put the Fireplace box into the wall. Align the two hanger brackets in both sides of the fireplace box
with the studded frame of the wall cut-out and using 6 pcs of ST4X 16 screws(each side with 3 screws)
to lock the fireplace in the wooden wall (Figure C).
**Note: If mounting fireplace below a TV, please leave at least 12” between top of fireplace and
bottom of TV.
ALWAYS unplug this fireplace heater before assembly or cleaning, or before relocating.
Failure to do so could result in electric shock, fire, or personal injury.
