5. NOMENCLATURE

• Main unit

• Lavalier microphone (WM-3310 only)

• Headset (WM-3310H only)

Power/Battery lamp
(Orange LED)

Power ON/OFF switch
(push lock)

Antenna

Audio level control

Channel selector switch

Clip
(Rotates 360

°.)

23.5

102

142

[Top]

[Front]

[Side]

[Rear]

[Inside of a battery cover]

ш3.5

Plug lock

Microphone

Crip

This part
rotates 360

°.

Tie-clip attachment

Windscreen

Plug lock

Gooseneck

6. BATTERY INSERTION

Step 1. Holding the microphone body, slide the

battery cover down to open it.
The battery cover is designed not to be
removed from the body.

Step 2. Insert the battery 6LR61 (Alkaline 9 V) according to the instructions

attached to the inside of the battery compartment. Pay attention to the
correct polarity when inserting the battery.

Step 3. Replace the battery cover.
