Toa WM-3220 - Manual (Page 4)

Printed in Taiwan
1 3 3 - 0 7 - 2 1 1 - 4 B
Model No. WM-3210 WM-3220
Microphone Element Dynamic type, Electret condenser type,
cardioid pattern cardioid pattern
Emission F3E
Frequency Range 169 – 216 MHz, VHF
Selectable Channel 6 channels
RF Carrier Power Less than 50 mW
Tone Frequency 32.768 kHz
Maximum Input Level 125 dB SPL 120 dB SPL
Maximum Deviation ±15 kHz (FCC Part 90), ±40 kHz
Audio Frequency Response 150 – 12,000 Hz 200 – 12,000 Hz
Dynamic Range (AF Circuit) More than 95 dB (with WT-3810)
Battery 6LR61 (9 V x 1)
Battery Life More than 10 hours (alkaline)
Indicator Power/Battery lamp (orange LED)
Antenna Built-in type
Operating Temperature –10 to +50°C
Finish Resin, coating, dark gray
Dimensions ø50 x 235.2 mm ø45 x 235.2 mm
Weight 250 g (with battery)
10. SPECIFICATIONS
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Microphone holder (with stand adapter) ............... 1
Screwdriver (for setting) ....................................... 1
License requirement
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
