5
6. OPERATION
6.1. Basic Operation
Step 1. Turn power on.
Step 2. Set the microphone switch to the ON position.
The reception lamp (No.9) lights when the tuner receives the same frequency signal.
Step 3. Adjust the volume control (No.2).
The output level increases as the control is rotated clockwise, and decreases as rotated
counterclockwise. Adjust the output to the level at which the AF peak indicator occasionally lights.
Notes
• When using the supplied rod antenna, ensure that it is fully extended.
• The AF signal indicator lights when the microphone is used regardless of the output volume setting.
(Light-activation level: Input level that is 40 dB lower than the maximum input sound pressure level.)
6.2. Channel Number Setting
Step 1. Hold down the Channel select key (No. 5) for 1 second or more.
Step 2. Channel indicators 1 – 6 (No. 4) will light in rotation. Release the Channel select key for the desired
channel.
Step 3. The channel will be set.
Note: Make sure that the wireless microphone and the tuner are identical in channel number.
7. HOW TO CHECK AND DEAL WITH INTERFERENCE
7.1. Order of Actions (Action Flowchart)
Change current channel number to idle channel
number.
It is convenient to use "Channel Check" key
when selecting idle channel numbers.
Adjust squelch control to limit service area.
No problem
When radio interference is still encountered,
consult shop from where unit was purchased.
Any
interference?
Refer to "6.2. Channel Number Setting" above.
Refer to p. 6 "7.2. Channel Detection."
Refer to p. 6 "7.3. Squelch Adjustment."
[No]
[Yes]
No problem
Any
interference?
[No]
[Yes]
No problem
Any
interference?
[No]
[Yes]
