TC-Helicon Vocal Technologies
www.tc-helicon.com
.
TC-Helicon Quintet MIDI System Exclusive
Version 1.1
Note: All numerical values will appear in HEXADECIMAL notation unless otherwise indicated:
0xF0 = F0h = F0 – The latter value is the expression of the hex numeral used.
Decimal equivalents will appear in brackets after their hex counterparts:
0xF0 = F0h = F0 = (240)
0x64 = 64h = 64 = (100)
General message format:
F0
MIDI System exclusive message start
00 3 byte manufactors ID for TC-Helicon
01 ...
38 ...
System exclusive device ID (user parameter)
4D Quintet model ID
Quintet message type identifier (see table below)
Data – depends on message type (see format description.
below)
…
…
F7
MIDI System exclusive message terminator
Preset numbers
Preset numbers are represented in the SysEx messages as 1 byte.
Preset number zero is the currently edited preset, and 1 to 50 are as is.
Message data format
The format of the data used/needed in the different SysEx messages depends on the type of
message. Below are descriptions for each message type explaining data formatting.
SysEx message type Identifier
Quintet Request Preset 17
Quintet Request All Presets 16
Quintet Preset Data Package 18
All CCs Request 32
