Before you begin

4 VoiceLive 3

Diagrams

3

4

5

5

To give you clear and concise representations of
what goes where, we have provided several con-
nection diagrams in the “Making connections”
(page 6) s
ection. There are a few things we
would like you to keep in mind as you follow
these diagrams:

– Signal sources that go into your VoiceLive  3

(e.g. microphone or guitar) will always be
shown to the left of the back panel image

(1)

.

– “Downstream” devices (mixers, speakers) will

always be shown to the right of the back panel

(2)

.

– The box in the lower left corner shows what

signals you will hear from the VoiceLive  3
headphone output.

– The box in the lower right corner shows what

you will hear from your mixer / PA speakers.
This could be anything from a “stick system”
or a portable/all-in-one loudspeaker system
to powered studio monitors or even a DAW
recording interface.

In many cases, what you hear from the Voice-
Live 3 headphone output and your PA will be the
same

(5)

– but it can also be different.

Please note that we do not account for other in-
puts or instruments in these diagrams – so you
won’t see pictures of drums

(4)

etc. When a set-

up example includes a connection to your guitar
amp, we do not show that amp being miked and
sent through the PA (which often is the case) –
we are just showing you how to connect Voice-

Live 3 in a particular setup. This means the “what
you hear” section in the lower right corner does
not show guitar sounds coming from the PA –
even though they might at a gig.

Legend

The following symbols are used in the setup ex-
amples section of this quick guide:

XLR Male

XLR Female

Combo Jack

MIDI Jack

1/4 inch jack

Power Input

Mini USB

1/8 inch jack
