Step 2: Assemble Grill Cart
1. Place the cart side left onto the two (2) outer caster assembly bolts, make sure the large
flange is toward the front of the cart base.
2. Secure the cart side left in place by tightening the caster assembly nuts onto the caster
assembly bolts.
3. Use six (6) self-tapping screws to secure the two drawer slide rail brackets onto the cart
side left as shown.
Note: Install the self-tapping screws from outside of cart so that the point of screw
is in the inside of the cart.
A. Cart base
B. Cart side left
C. Drawer rail brackets
D. Wheel channel assembly bolt
E. Wheel channel assembly nut
A
B
C
D
E
ASSEMBLY INSTRUCTIONS
9
