Sure Heat 2007 Amana AM30 - Manual (Page 11)

STEP FOUR
a. Loosen the four (4) grill mounting bolts so that there
is approximately 1/4” between the bolt head and
grill bottom.
b. Have someone help you pick up the grill and set it
squarely on top of the cart.
c. Make sure the four (4) bolts fall through the large
opening on the “ key hole” slots on the sides of
the cart.
d. Slide the grill forward in the “ key hole” slots until
the front grill flange rests against the side cart
flanges. Check on the inside of the cart to make
sure that both sides of the grill are flush with the
cart.
e. Install two (2) self tapping screws into the top left
and right cart flanges.
f. Tighten the four (4) grill head mounting bolts
underneath the grill to secure the grill to the cart.
SS 4 Assembly
11
close-up steps 4c - 4f
Repeat for all 4 corners.
4e
4a
4d
4c
4b
