SS 4 Assembly

STEP THREE
a. Press the sides back together making sure that the

side flanges cover the cart back flange.

b. Attach three (3) self tapping screws through the

pre-drilled holes on the left cart side into the cart

back. Repeat for right cart side.

c. Fasten two (2) nuts onto the back wheel channel

bolts.

d. Tighten all six (6) wheel channel nuts with a

wrench.

e. Attach the Spare L.P. Gas Tank Barrier by

inserting the tabs into the slot on the base of the

cart, and then attaching the flat end of the

bracket to the pre-drilled hole at the back of the

cart with a self-tapping screw. Make certain to

attach the self-tapping screw from the

outside of the cart.

The Spare L.P. Gas Tank

Barrier must be installed

to prevent storage of spare L.P. Gas

Tanks. Failure to comply with these

instructions could result in a fire or

explosion that could cause serious

bodily injury, death, or property dam-

age.
