SF8
SF10
8-inch two-way, passive
10-inch two-way, passive
Live Sound, Speech, Playback, DJ, A/V, Institutional Venues
Features General Description
MADE IN CHINA
SF8 SF10
Model No. SF8 SF10
Type 8-inch, two-way 10-inch, two-way
150 W / 600 W 150 W / 600 W Power Handling RMS/Peak
8 Ω 8 Ω
Sensitivity @1W/1my
Rated Impedance
93 dB SPL 94 dB SPL
Frequency Response (-10 dB) 62 Hz - 20k Hz 60 Hz - 20k Hz
Max. Peak SPL 120 dB 121 dB
Crossover 2.4 k Hz 2.4 k Hz
Connectors 1x Speakon-style + 1x 1/4" 1x Speakon-style + 1x 1/4"
Protection Internal overload Lamp on HF driver Internal overload Lamp on HF driver
Mounting Method Integral 1 3/8” Pole Mount Receptacle Integral 1 3/8” Pole Mount Receptacle
Angles for floor Monitor 45˚ & 55˚ 45˚ & 55˚
HF Horn Coverage, Angles(-6dB) 90°H x 45°V 90°H x 45°V
Enclosure Material PP PP
Suspension 4×M8 (2 on top, 2 on bottom) 4×M8 (2 on top, 2 on bottom)
Finish Black Black
Transducers/ Replacement Parts LF: L8G Ferrite driver, 8" (203 mm)
HF: H25G, 1" (25 mm)
LF: L10G Ferrite driver, 10" (254 mm)
HF: H25G, 1" (25 mm)
Dimensions(HxWxD) 45.5 Ч 27.5 Ч 26.1 cm
17.9 Ч 10.8 Ч 10.3 in.
54.3 Ч 33.5 Ч 32.4 cm
21.4 Ч 13.2 Ч 12.8 in.
Net Weight 6.2 kg (13.6 lbs) ) 8.4 kg (18.5 lbs)
Shipping Weight 8.2 kg (18.1 lbs) 10.4 kg (22.9 lbs)
SOUND REINFORCEMENT LOUDSPEAKERS
The SF8 and SF10 set a best value for passive speakers.
Their design provide the user an easy to use, reliable HF
protection circuit and high power handling in a very
compact, attractive package. Both of them are full range
loudspeaker ideal for applications requiring high-quality
sound. Careful attention to the dynamic requirements of
music guided the design to provide high SPL. Built-in pole
mount and optional rigging hardware make it easy to
position for your application. The high-frequency section of
the SF8 and SF10 utilizes an integrated 90° x 45° horn to
ensure high intelligibility. Vocals sound natural yet “cut
through” reverberant, noisy rooms. The SF8 and SF10's
high-frequency horn is driven by the H25G, a 1 inch
diaphragm, wide-bandwidth, titanium-diaphragm driver for
smooth and extended high-frequency response.
• High power handling: 150W RMS; 600W peak
• High-output precision titanium compression driver
• High sensitivity long-throw low frequency transducer provides
incredibly deep bass and acoustic power
• Ultra-wide, smooth dispersion
• Overload-protection circuitry ensures optimal HF driver protection
• Additional link output allows linking of additional speaker systems
• Molded composite cabinet with lightweight for ultimate portability
• Ergonomically shaped handles for easy carrying and setup 45 or 55
degree angles for aiming up toward performers when used as a loor
monitor
• Flyable, pole mountable, floor wedge-able, and wall mountable
Part Numbers: LB100SF100102
