Superlux SP108 - Manual

SP108
Portable PA System
Travel musician
Busker
Guitarists
Public Speakers
Vocalists
Performers
• Easy to carry, transport and setup.
• 8-ch powered mixer with 150W+150W class D power amp, 2-band channel EQ digital
reverb, and mic stand mountable.
• Powered mixer can be used either while installed in the speaker compartment or
detached for easy positioning and access.
• Using optional microphone stand adapter, the powered mixer can be mount on a
microphone stand.
• Storage compartment in the speaker cabinet for packing the included cables, and your
microphones.
• 8 2-way speakers can be used as mains or floor monitor.
• 120V WH00SP1080100
• 230V WH00SP1080101
2x 8 2-way speakers
1x 8-CH Powered Mixer
2x speaker cables, 5 meter
1x power cord
The SP108 compact design allows for ease of transportation, while its user-friendly
controls offer ease of operation, making it the perfect choice for schools, churches,
civic organizations and small musical groups. The SP108 features dual two-way
speakers driven by a eight-channel, 300 Watt stereo powered mixer, making it ideal
for both vocal and musical applications. Among many professional features, the
mixer includes digital reverb and music/speech switch. The convenient accessory
compartment storage for cables and additional microphones. This clever design
allows the powered mixer to be installed in the speaker compartment or detached for
easy positioning and access. The SP108 is a high-performance live-sound system
that will deliver your music or message where you go, indoor or out.
Maximum Output Power
Frequency Response
Total Harmonic Distortion
Hum & Noise
(20 Hz–20 kHz, Rs=150 ,
MIC/LINE switch=MIC)
Crosstalk (1 kHz)
Weight
Power Consumption
I50 W+150 W/6 @10 % THD at
1 kHz (SPEAKER L/R)
20 Hz -20 kHz
0.5% @ 20 Hz -20 kHz, +14 dBU
-67 dBu Residual output noise
(SPEAKER L/R)
-88 dBu Residual output noise
(MONITOR OUT, REC OUT)
-70 dB between input channels
16.9 kg (mixer and two speakers)
70W
Enclosure
Speaker Unit
Cross Over Frequency
Frequency Range
Maximum Output Level
Bass-reflex type
LF: 8" (20 cm) Cone
HF: 1" (2.54 cm) Compression
Driver
4 kHz
55 Hz–20 kHz
112 dB (1 m)
Shelving turnover/rolloff
frequency
3 dB before maximum cut or boost.
15 dB
HIGH 10 kHz shelving
LOW 100 Hz shelving
Specifications
Features
SP108 Part Numbers
System Includes
General Description
www.superlux.com.tw
Stereo Input Channel Equalization
Speaker
