Package features description, Supplied accessories optional accessories, Pra218b – Superlux DRKK5C2 User Manual
Page 2: Mounting the microphone, Type of transducer, Maintainence
Package
Features
Description
PRA218B
The DRKK5C2 combined 7 professional microphones for picks up a drum
set. These microphones are 1 PRA218B for kick drum, 3 D10C for tom-
tom, 1 D10D for snare, and 2 E102 for overheads. These high quality
microphones can also be used for various instruments, such as strings
and winds.
Large deluxe aluminum carrying case.
D10C
D10D
E102
! Control boost at 60~100Hz and 2.5KHz for rich and punch sound.
! High SPL, large dynamic range, and low distortion
! Suitable for low frequency instruments, such as kick, floor tom,
timpani, bass guitar
! Unique mid bass response for strong and realistic drum sound that
emphasis drum characteristics.
! Large dynamic range, low distortion.
! Suitable for mid-bass instruments, such as tom-tom, floor-tom or
guitar.
! Unique mid high band response for reach sound.
! Clean, bright and crisp penetrated sound characteristic.
! For high SPL, large dynamic and low distortion.
! Suitable for winds and electric guitar.
! Very good response for high frequency instruments such as cymbal
and hi-hat.
! High SPL, large dynamic and low distortion
! Suitable for piano, harp, cymbal, and percussions.
E102
TYPIC AL POLAR PATTERN (Fig ure 7)
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
D10D
TYPIC AL POLAR PATTERN (Fig ure 5)
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
D10D
TYPIC AL FREQUENCY RESPONSE (Fig ure 6)
F
R
E
Q
U
E
N
C
Y
I
N
H
z
F
r
e
q
u
e
n
c
y
R
e
s
p
o
n
s
e
R
E
L
A
T
IV
E
R
E
S
P
O
N
S
E
I
N
d
B
dB
10
-10
-20
20
50
100
200
500
1000
2000
5000
10000
20000 Hz
0
E102
TYPIC AL FREQUENCY RESPONSE (Fig ure 8)
F
R
E
Q
U
E
N
C
Y
I
N
H
z
F
r
e
q
u
e
n
c
y
R
e
s
p
o
n
s
e
R
E
L
A
T
IV
E
R
E
S
P
O
N
S
E
I
N
d
B
dB
10
-10
-20
20
50
100
200
500
1000
2000
5000
10000
20000 Hz
0
Adjustable boom stand --------------------------------------- MS131
Elastic shock mount ------------------------------------------ HM32
Table stand --------------------------------------------------- HM6
Supplied accessories
Optional accessories
1 x HM27 Mic. clip for PRA218B
4 x HM28 Mic. clip for D10C and D10D
2 x HM10B Mic. clip for E102
4 x HM12A drum clamps
7 balanced XLR3M-XLR3F cables. One of the cable equiped with 90
degrees angle female plug for kick drum microphne (see the
attached
figure).
XLR3F-XLR3M Mic. Cable
XLR3F-XLR3M Mic. cable,
90 degrees angle female plug
Mounting the microphone
Pressure gradient microphone is very sensitive to vibration. Suitable shock mount for high performance microphone is
necessary for extreme low noise recording. Sturdy stand can set the microphone excatly at the sweet spot and keep it
there. Choose heavy duty microphone stand for studio condenser microphone which weights much more than handle
microphone.
Superlux provides wide range of microphone stands for various demands. Big Foot Willie is specially developed for large
condenser microphones that able to support 2 large microphones with stereo bracket for single point stereo recording.
Extension foot on all the 'E' versions serve to mount heavy studio microphone in limit space live sound applications.
Narrower than cardioid pattern. Suitable for multiple microphone setup. Least sensitive angle pointing toward side to rear
where most stage monitors are located. Same proximity effect as cardioid microphone.
Super Cardioid
Extremely light weight diaphragm, very sensitive to
sound. Very small versions available for hiding
applications. High performance condenser microphones
are regarded as standard equipment of recording studios
for extreme detail capturing. Operates with power, such as
phantom or battery.
Durable and simple structure, operates in all kinds of
environments. A good dynamic microphone is capable to
operate at very high sound pressure level without
distortion. Due to structure limit, dynamics cannot be
built as small as condenser, but dynamics
doesn require power to operate.
Type of transducer
Condenser
Dynamics
Maintainence
Condenser microphone shall be kept in low humidity environment for best sound performance. Store the condenser
microphones in airconditioned room or dehumidifier to keep away form moisture. Clean air is another important factor.
Keep away from smoking environment to avoid tar residuals.
6
5
4
