Instruction Manual
7
Specifications
Card Interface 32-bit PCI (5v), 64-bit PCI-X (3.3v)
FIFO Size 128 KBytes software, 32 bytes hardware
Max. Data Transfer Rate 920 Kbits/sec., supports both full and half duplex
Connectors
1 x proprietary 44-pin (female) to dongle
4 x DB9 (male) to peripherals
1 x internal SP4 (male) power connector
Signal Types Supported
RS-232 Serial
TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND (see below
for pinout)
Power to Peripherals
5 or 12 volts to peripheral supported over DB9
connection
OS Support
Windows 2003 Server, XP, 2000, Vista, 7 (32 & 64-bit)
Driver support included for 64-bit editions of Windows
2003 and 2000 Server.)
Operating Tolerances 32º~135ºF (0º~57ºC), 5~95% rel. humidity
UART Chipset Sunix SUN1889 (16C650 compliant)
Certifications Regulatory: FCC Class B, CE Other: Microsoft WHQL
