6
Specifications
Host Interface
PCI revision 2.3
(3.3V/5V, 33/66MHz)
Form Factor Full/Low Profile
Chipset ID SystemBase SB16C1052PCI
External Connectors 2 x 9-pin DB9 male
Supported Protocols RS485, RS422
Data Bits 5, 6, 7, 8
Stop Bits 1, 1.5, 2
Maximum Data Transfer Rate 128,000 Kbps
Buffer Size 256 Byte Tx/Rx
Operating Temperature 0°C ~ 85°C (32°F ~ 185°F)
Storage Temperature -40°C ~ 85°C (32°F ~ 185°F)
Dimensions 120.0mm x 45.0mm x 18.0mm
Weight 55.8g
Compatible Operating Systems
Windows 2000/XP/Server 2003/
Vista/Server 2008 R2/7 (32/64-
bit), Linux kernel 2.4.x/2.6.x
