Instruction Manual
2
Assembled Adapter View
Assembled Adapter View
1. Top mounting holes
2. Side mounting holes
3. SATA DATA & Power Combo (7+15 pin)
4. HDD plate
5. HDD plate mounting holes
Open Adapter View
1. M.2 (NGFF) SSD Connector
2. Drive installation bracket
3. Drive length adjustment holes
4. HDD plate mounting holes
1
1
1
1
1
2
2
2
3
3
5
5
5
5
4 4
4 4
4
