Instruction Manual
6
Specifications
Number of Ports 5 8
Compatible Network Types 10/100Mbps
Supported Standards IEEE 802.3, IEEE 802.3u
Connectors
5x RJ45 Ethernet Female
1x DC Power
8x RJ45 Ethernet Female
1x DC Power
LED Indicators
1x Power
5x Port Link/Activity
1x Power
8x Port Link Activity
Chipset ID Atheros AR8236 Realtek RTL8309G
Auto MDIX Yes
Full Duplex Support Yes
Switch Architecture Store and Forward
Supported Protocols CSMA / CD
MAC Address Learning Auto Learning, Auto Aging
Flow Control IEEE 802.3x
Maximum Cable Length 100m
Power Adapter 5V DC, 600mA, center positive
Enclosure Material Plastic
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -40°C ~ 70°C (-40°F ~ 158°F)
Humidity 10 ~ 90% RH
Dimensions (LxWxH) 140.4mm x 89.1mm x 28.0mm
Weight 205g 235g
