Top view side view – StarTech.com SATDUPUEGB User Manual
Page 5
Instruction Manual
2
Top View
Side View
Progress Bar (DUP)/
Drive Activity (PC) LED
Start Duplication
Button
Drive Detect LED
(Source)
Mode Selection
Button
USB mini-B
Connector
Mode Indicator
LED
Power Button
Drive Detect LED
(Destination)
Power Connector
eSATA Connector
SATA Data/Power
connector (Source)
SATA Data/
Power connector
(Destination)
*actual product may vary from photos
