StarTech.com S352BU33HR Manual - Manual (Page 10)

Instruction Manual
7
a) Ensure the S352BU33HR is powered off.
b) Adjust the RAID Control Switch to your desired RAID configuration (See Available
RAID Configurations).
c) Press and hold the set RAID button while turning on the S352BU33HR on by
pressing the Power Button.
Note: RAID configuration is only required for initial configuraiton or if you would like to
change your RAID configuration.
Available RAID Configurations
The S352BU33RER enclosure supports 4 different RAID configurations. RAID is a
storage technology that combines multiple hard drives into a single unit for secure
data redundancy, increased volume size and/or improved performance.
Descriptions and benefits for each available RAID configuration are listed below:
JBOD - Normal
In JBOD, no RAID configuration is set and both drives appear as individual disks.
Note: For both drives to be detected while connected via eSATA the host controller
must support SATA Port Multiplier.
