StarTech.com SV831DUSBAU - Manual (Page 18)

Instruction Manual
15
Specifications
Maximum # of connected
computers (Cascaded)
64
Maximum Video Resolution 1920 x 1440
Storage Temperature -20° ~ 60° C
Storage Humidity 0-80% RH
Operating Temperature 5° ~ 40° C
Operating System Support OS Independent (transparent)
Number of Computer Ports 8
KVM Console Interface USB
Console Connectors
1 x DE-15 VGA female
2 x USB type A female
2 x 3.5mm Audio Mini-Jack female
Computer (PC) Connectors -
Per Port
1 x DE-15 VGA female
2 x 3.5 mm Audio Mini-Jack female
Power Consumption (Max.) 9-12VDC, 500mA
Dimensions - H x W x L 45 mm (1.77”) x 180 mm (7.09”) x 548mm (21.3” )
Weight 2.6 kg (91.78 oz)
