Optional: Rack Mount Installation
The following illustration depicts how to attach optional mount brackets and cable
support for rack mounting SV431USBAE. To do so, you may wish to use SV431RACK
(please see Accessory Products from StarTech.com for further information).
1
1
2
3
2
1
2
3
To the Rack Cabinet
back post
USB or Monitor
cables to switch
Two screws secure
the cable support
