Instruction Manual
3
Connecting Slave Computers
1. Connect the VGA port located on the rear panel of SV431USBAE to the VGA port
provided by the video connection on the desired computer, using an HDB15 male
to female cable. Please note the PC Port number, for steps 2 and 3.
2. Using a USB A-B Cable, connect the USB port that corresponds with the PC port
used in step 1, to the USB port on the corresponding computer, as shown below.
3. Optional: Using an audio cable (Speaker and Mic), connect the Speaker and Mic
ports provided by the PC port used in step 1 on SV431USBAE to the Speaker and
Mic ports located on the computer.
4. Repeat steps 1-4 as necessary for each computer you wish to connect. Once all
computers have been connected, you can turn on all devices and computers.
Audio Cable
(Speaker and Mic)
USB Patch Cable for
Mouse and Keyboard
Male-to-Female
HDDB15 for VGA
