Instruction Manual
5
Specifications
Video Signal Input
Standard HDMI (1.2)
DVI 1.0
Video Signal Output Composite video
Connectors
1 x HDMI type A female
1 x RCA Composite Video female
2 x RCA Stereo Audio female
1 x DC Power
LEDs 1 x Power
Supported Video Systems NTSC, PAL
Supported Video
Resolutions (Input)
HD: 720p, 576p, 480p @ 60Hz
PC: 1280x800, 1280x768, 1224x768, 800x600,
640x480 @ 60Hz
Supported Video
Resolutions (Output)
480i, 576p
HDCP Support Yes (v1.1)
Supported Audio LPCM 2-Ch, 48KHz
Enclosure Material Plastic
Power Adapter 5V DC, 1000mA, center positive, type M plug
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
Humidity 20% ~ 90% RH
Dimensions (LxWxH) 65.0mm x 114.0mm x 26.0mm
Weight 120g
