Operation Controls and Functions
Front Panel
1. PC Input: Connect the D-Sub (15-pin) VGA PC input port to the DB15 VGA output port
of your source equipment.
2. Audio Input: Connect the 3.5mm jack input port to the analog audio port of your
source equipment.
3. TOSLink (Optical Fiber) Input: Connect the optical input port to the digital audio
output port of your source equipment.
4. Power: Plug the 5VDC power supply in to the unit and connect the adapter to an
available AC wall outlet.
1
2
3
4
