Instruction Manual 1
Introduction
Packaging Contents
• 1 x VGA Video Extender Local Unit
• 1 x VGA Video Extender Remote Unit
• 1 x Mounting Bracket Kit
• 2 x Power Adapters
• 1 x Instruction Manual
System Requirements
• VGA enabled video source and display
• Available AC electrical outlet at local and remote locations
• VGA male/female cable to connect video source to extender
• VGA male/male cable(s) to connect display devices to extender
Installation
Hardware Installation
This product is composed of two different units: the Local Unit and the Remote Unit. The
Local Unit takes the output from a VGA signal source (usually a computer) and transmits
it to the Remote Unit over Category 5 Ethernet cable. The remote displays (monitor,
projector, etc) connect to the Remote Unit using standard VGA connections and displays
the image from the local computer onto the remote displays.
