Instruction Manual 1
Introduction
Packaging.Contents
• 1 x VGA Video Extender Transmitter Unit
• 1 x VGA Video Extender Receiver Unit
• 1 x Power Adapter
• 1 x Mounting Bracket
• 1 x Instruction Manual
System.Requirements
• VGA capable output on video source
• VGA capable monitor/display device
• VGA male/male cables to connect video source and display device
• Available AC electrical outlet at either transmitter or receiver location
Installation
Hardware.Installation
1. Turn off the PC and remote display.
2. Connect the ST121UTPEP Transmitter unit’s “VGA In” connector with a standard VGA (DE-15)
male to male cable to PC video card.
3. Connect the ST121UTPEP Transmitter and ST121UTPEP Receiver units together with a straight
through Cat5e cable.
4. Connect the ST121UTPEP Receiver unit’s “VGA Out” connector with a standard VGA (DE-15)
male to male cable to the monitor/display.
5. Connect the power adapter to either the Transmitter unit or Receiver Unit, whichever is more
convenient. It is not necessary to have power connected to both.
6. Turn on the monitor and PC.
