Instruction Manual
4
3. Install receiver unit
a) Position the receiver unit near the video display (i.e. television, projector).
b) Connect the video source to the HDMI® out port on the receiver unit using an
HDMI® cable.
c) (Optional) If you’ve chosen to connect the power adapter to the receiver unit,
connect the power adapter from the power adapter port to an available wall outlet.
4. Your source video image will now appear on the remote video display.
Specifications
Local Unit Connectors
1x HDMI® (19 pin) Female
1x RJ-45 Female
Remote Unit Connectors
1x HDMI® (19 pin) Female
1x RJ-45 Female
Maximum Data Transfer Rate HDMI® - 3.4Gbps
Max Distance 100 m / 330 ft
Maximum Digital Resolutions 1080p @ 60Hz, 48-bit
Wide Screen Supported Yes
Audio Specifications Supports Dolby® TrueHD, DTS-HD MA
